Hachette ALIEN - Kit 5: Skull & Appendages Assembly

PB
1
ASSEMBLY GUIDE
5-1
5-6
5-8 5-9
5-7
5-2
5-4
5-3
5-5
In this kit you will continue the assembly of the skull of the Xenomorph and
start to fix some of the appendages to the left-hand side.
KIT 5: SKULL &
APPENDAGES
PARTS SUPPLIED
Ref. Name Qty.
5-1 Skull C 1
5-2 Skull Pipe 1 1
5-3 Skull Pipe 2 1
5-4 Skull Pipe 3 1
5-5 Skull Pipe 4 1
Ref. Name Qty.
5-6 Skull Pipe 5 1
5-7 Skull Pipe 6 1
5-8 Skull Pipe 7 1
5-9 2.3x6mm screws 3*
*A spare screw is supplied in case of loss or damage.
