KIT 6: FRONT-LEFT SECTION OF THE HEAD
1
3
2-1
2-1
2-3
2-3
2
2-1
6-2
4
6-1
6-3
Take the lower jaw assembly from kit
2 and gently remove the Side Panel
2-3 from the Lower Jaw A 2-1.
Fit the Washer 6-2 into the
opening in the Lower Jaw A
2-1, as shown.
Re-t the Side Panel 2-3
by inserting its pegs into
the corresponding holes.
Do not glue in place as it
will be temporarily removed
again in a later kit.
Test-fit the Pipe 6-3 into
the slots on the front-left
section of the Head 6-1.
When sure of a good fit,
apply a little glue to the
tabs on part 6-3 and
secure firmly in place.
