Hafco BM-53VE - BM-23 A Belt Driven Head Identification

6
OPERATION MANUAL
BM-23A
Belt Drive Head
Belt Tension
Adjustment Lever
Belt Housing
Spindle Safety Cover
Spindle Speed
Range Selector
Coarse
Downfeed Lever
Quill Lock
Lever
Adjustable
Downfeed Stop
Spindle
Brake Lever
High/Low
Range Lever
Fine Downfeed
Handwheel
Auto-Downfeed
Direction Pin
Fine Downfeed
Clutch Lever
Auto-Downfeed
Rate Selector
Quill & Spindle
Manual/Power
Downfeed Selector
Motor Lock
Screw
Fig. 2
BELT DRIVEN HEAD IDENTIFICATION
Page 6
Instructions Manual for BM-23A (M595D)
12/02/2018
