Mounting Instructions
33
6. Remove the door handle from the external square spindle.
The Door Terminal Basic is adapted for a right-facing door
handle.
Proceed as follows if the pins have been inserted in the wrong
side:
Ö
Remove the 8 screws in the fixing plate.
Ö
Remove the fixing plate from the bracket.
Ö
Pull the pins out of the bracket, using pliers if necessary.
Ö
Place the fixing plate on the bracket.
Ö
Tighten the screws.
Ö
Repeat the adaptation process for the correct hole location.
