Technical data
Seite 19 von 130
DALI:
Voltage: typically 16 V DC
with over-voltage protection
Current: typically 128 mA, max. 200 mA temporarily
designed for a maximum of 64 DALI devices at 2 mA
with short-circuit and overload protection
Transmission rate 1200 bit/s
Protocol: acc. to DIN EN 60929 appendix E4
Cable lengths between
Gateway and device:
∅ 1,5 mm²
max. 300 m
∅ 1,0 mm²
max. 238 m
∅ 0,75 mm²
max. 174 m
∅ 0,5 mm²
max. 116 m
Resistivity:
max. 4
Ω (single length) / max. 8 Ω (main and return cable)
Cable type: Specified by functional extra-low voltage. (FELV) /
Preferably 2 free wires of a NYM installation line.
