"DALI Gateway C00Cx2" software
Functional description
Seite 62 von 130
Setting the cyclical transmission function for the brightness feedback telegram
In addition to being transmitted in case of an update, the brightness value feedback telegram can also
be transmitted cyclically via the active message object.

Set the “Cyclical transmission of feedback telegram?” parameter in the "Groups - [x] group name -
dimming" parameter node to „Yes“.
Cyclical transmission is now activated.

Set the “Cyclical transmission of feedback telegram?” parameter in the "Groups - [x] group name -
dimming" parameter node to „No“.
Cyclical transmission is now deactivated meaning that a feedback telegram is transmitted to the bus
only if a brightness value has been updated.
• The cycle time is defined centrally for all DALI groups in the “Groups” parameter node.
• During an active delay time, no feedback telegram will be transmitted even if a brightness value has
changed.
