Haier 1U12BS3ERA - Specifications

 Specification
 Domestic air conditioner
2 Specifications
NOMINAL DISTRIBUTION SYSTEM VOLTAGE
Phase / 1
Frequency Hz 50
Voltage V 230

NOMINAL CAPACITY and NOMINAL INPUT
 cooling heating
Capacity rated
KW 3.6 3.7
Btu/h 12290 12630
Power Consumption(Rated) KW 1.35 1.40
SEER/SCOP W/W 6.1 4.0
Annual energy consumption KWh 1321
Moisture Removal m³/h

TECHNICAL SPECIFICATIONS-UNIT
Dimensions H*W*D mm 780×245×540
Packaged
Dimensions
H*W*D mm 920×351×620
Weight / KG 31.2
Gross weight / KG 34.2
Sound level
Sound peessure dB 51
Sound power dB 62

ELECTRICAL SPECIFICATIONS
cooling heating
Nominal running current A 4.6 4.3
Maximum running current A 6.2 6.4
Starting current A 1.2 1.2

TECHNICAL SPECIFICATIONS-PARTS
 cooling heating
Compressor
Type Rotary Compressor
Model 5RS092ZKD21
Motor output W 700
Oil type FV50S or equivalent
Oil charge volume L 0.32
Fan
Type Axial fan
Motor output W 40
Air flow rate(high) m³/h 31.7
Speed(high/low) rpm 1119
Heat
exchanger
Type
ML fin-¶9.52HI-HX tube
Row*stage*fitch 2*20*1.32
1.6*10 ³

7
