Haier AC142ACAAA - Name of Parts

NAME OF PARTS
5
Fig.1 Indoor Unit
1 Operating Control Panel (Fig.2)
2 Emergency switch
3 Remote Control Signal Receiver
4 Power Indicator Lamp (Red)
5 OPERATION Indicator Lamp (Green)
6 TIMER Indicator Lamp (Yellow)
7 Compressor Run Lamp (Green)
8 Intake Grill (Fig.3)
9 Air Filter
10 UP/DOWN Air Direction Flaps
11 RIGHT/LEFT Air Direction Louvers
(behind UP/DOWN Air Direction Flaps)
12 Power Plug
Fig.4 Outdoor Unit
13 Intake grill 14 Outlet grill 15 Pipe Unit
3
1
9
8
Fig.1
12
1110
for series 14,18
For series 24,28
4
6
7
3
Fig.2
POWER
OPER
TIMER
COMP
EMER
2
4
5 6
2
3
POWER OPER
TIMER
EMER
Fig.3
Fig.3
14
13
15
Fig.4
For series 36,42 For series 14,18
for series 36,42
for series 24,28
5
