Wiring connection
Make wiring to supply power to the outdoor unit, so that the power for the indoor unit is supplied by
outdoor unit
.
Outdoor 3 phase type
Outdoor unit
terminal block
Indoor unit
terminal block
Power supply:1PH,220-240V~,50/60Hz
Y/G
1 2 3
Y/G
1 2 3
L N
Outdoor unit
terminal block
Indoor unit
terminal block
Y/G
1 2 3
Y/G
1 2 3
R S T N
Outdoor single phase type
Electrical wiring
ADH200H1ERG
Power supply:380-415V, 3N~,50/60Hz
1UH200W1ERK
AD100S2SH5FA
AD125S2SH5FA
AD140S2SH5FA
AD160S2SH5FA
AD180S2SH5FA
1U100S2SN5FA
1U125S2SP5FA
1U140S2SP5FA
1U160S2SP5FA
1U180S2SP5FA
Installation Procedure
24
WIRED CONTROLLER& INDOOR PCB CONNECTION(one for one wiring type):
A
B
C
.
INDOOR UNIT PCB
CN22
WIRED
CONTROLLER
CON1
A
B
C
