5
Parts and Functions
POWER TIMER RUN
ON/OFF
Remote controller's infrared receiver
Emergency and Test Switch
"POWER" lamp (Green)
It lights up when the indoor Unit is started.
"TIMER" lamp (Yellow)
It lights up when "TIMER" function is acticated for programmed start/stop.
"RUN" lamp (Red)
It lights up when the compressor (Outdoor Unit) is operating.
Upper air outlet
LED Panel and IR Receiver
Inside air filter
Inlet grille
Iower air outlet
WARNING
Befor opening the frontal grille, stop the air conditioner and disconnect the appliance.
Never touch the metal pates inside the unit in order to avoid injuries.
Indoor unit
