6
Parts and Functions
ON/OFF button
Remote controller's receiver
Room temperature sensor
Remote controller's infrared receiver
It allows the reception of signals sent by the remote controller. If the signal is received,
the unit emits a "bip" confirmation sound.
ON/OFF button
When the remote controller is not available, press this button to start the unit. The fan
speed will be set to "AUTO". Press the button again to stop the unit.
Air outlet selector
It allows to select the airflow direction:
upwards and downwards at the same time:
In fan mode, press SLEEP button 6 times continuously,indoor buzzer sounds 2 times.
upwards only:
In fan mode, press SLEEP button 6 times continuously,indoor buzzer sounds 1 times.
Factory default (recommended)
The unit automatically adjusts the airflow direction on the
basis of the operation conditions and settings carried out
by the user
Alternative optional setting:
The unit emits air from the upper outlet only.
