21
Installation Precautions
1. In order to make the air conditioner work well, please
install the air conditioner in accordance with the
requirements of this manual.
2. When moving the air conditioner, be careful not to
scratch the surface of the casing.
3. Please use the connecting pipe supplied by the
company to connect the indoor and outdoor machines.
4. The maximum length of the connecting pipe is 20
meters, and the maximum height difference between
the indoor machine and the outdoor machine is 10
meter
s.
5. To prevent turning over, please do not push, pull the
indoor machine body..
6. After installation, please use the air conditioner
correctly according to the instruction manual.
7. Please keep the manual for use in repair or
replacement of the installation location.
Caution
This manual describes the use of Qingdao Haier Air-conditioner Limited Company set up the
installation of tools for air conditioners to install the method.
Driver
Torque wrench
(17mm,22mm,26mm)
Nipper
Reamer
Hacksaw
Pipe cutter
Gas leakage detector or
soap-and-water solution
Hole core drill
Flaring tool
Spanner(17,19 and 26mm)
Knife
Measuring tape
Necessary Tools for Installation
Selection of Installation Place
Place where it is easy to route drainage pipe
and outdoor piping.
Place away from heat source and with less
direct sunlight.
Place where cool and warm air could be
delivered evently to every corner of the room.
Place near power supply socket. Leave enough
space around the unit.
Place robust not causing vibration,where the
body can be supported sufficiently.
selection of installation place
Place strong enough to support the unit and wi
ll
not cause vibration and noise.
Place where discharged wind and noise
doesn’t
cause a nuisance to the neighbors.
Place where is less affected by rain or direct sunlight
and is sufficiently ventilated,or to install a shield.
Place with enough space for smooth air flow.
Selection of pipe
To this unit, both liquid and gas pipes shall be insulated
as they become Iow temperature in operation.
Use optional parts for piping set or pipes covered with
equivalent insulation material.
Installation of indoor unit
Installation of outdoor unit
Power Source
Accessory Parts
No. Shape QTY
1 Prevent fall parts 1
2 Dry battery 2
3 Drain Pipe 1
4 Bracket 4
5
cushion
6 Screw set / nuts 1
7 Wall hole cover 1
8 1
9
User manual
1
Remote controller
3
Plain
Before inserting power into receptacle, check the voltage
without fail.
The power supply is the same as the corresponding
nameplate. Install an exclusive branch circuit of the power.
A receptacle shall be set up in distance where the power
cable can be reached. Do not extend the cable by cutting it.
hsilgnE
6.35×0.53mm
12.7×0.8mm
