Functions and control
16 Domestic air conditioner
3 Wh_c<-2 Max_hz3 99HZ
4 Wh_c<4 Max_hz4 99HZ
5 Wh_c<10 Max_hz5 71HZ
6 Wh_c<17 Max_hz6 67HZ
7 Wh_c<20 Max_hz7 59HZ
8
Wh_c>
20
Max_hz8 48HZ
Remarks: The above are the maximum frequency limitations of the complete appliance which are
affected by the environment, and they have nothing to do with the ability of the indoor unit.
Refrigeration/dehumidification mode:
Serial No. Temperature scope
Frequency limitation
09K
1 Wh_c<16 Max_hz1 45HZ
2 Wh_c<22 Max_hz2 53HZ
3 Wh_c<29 Max_hz3 64HZ
4 Wh_c<32 Max_hz4 71HZ
5 Wh_c<40 Max_hz5 75HZ
6 Wh_c<48 Max_hz6 58HZ
7 Wh_c>=48 Max_hz7 39HZ
Remarks: the above are not only the maximum frequency limitations of the complete appliance
which are affected by the environment, but also the maximum ability limitation of the system. When the
starting ability is not the maximum, its maximum frequency limitation is calculated by the following
equations:
The frequency limitation which is affected by the temperature and under the condition of actual
ability
the actual running system ability*the maximum frequency which is limited by the temperature
and under the condition of maximum ability/the maximum designing ability of the system
Refrigeration/dehumidification mode:
Heating mode:
The calculation of the actual output frequency:
F= F-ED-*(rated frequency)
K
F-ED-*(rated frequency)= The frequency which is limited by the outdoor environment temperature
Notes:
When refrigerating, it is needed to satisfy
The indoor setting
airflow speed
Low Medium Quiet
The percentage of the
rated frequency K
(09K)
70% 85% 42%
The indoor setting
airflow speed
Low Medium Quiet
The percentage of the
rated frequency K
(09K)
80% 90% 50%
