Haier AS25THMHRA-C User Manual

Removal Procedure
3 Domestic air conditioner
Remove the air filters and horizontal flap
Step Procedure Points
6
Pull the Harness out of
the control box and then
release the pivots on
both sides of the unit
to remove the front
panel
Remove the air filters
1
Lift an air filter upwards
slightly and then pull it
out downwards
Remove the horizontal flap
1
Release the side of pivot
and then Release the
Center of the pivot.
Bend the horizontal
blade slightly and
remove it.
■ The horizontal
flap is Single
