Removal Procedure
8 Domestic air conditioner
Removal of Heat Exchanger
Step Procedure Points
1
2
Loosen the marked
screws(2EA)
Pull mounting plate
and heat exchanger
bracket out from
Hook of the base
frame and then
release them.
Loosen the Screws (2EA)
