DISASSEMBLY
⑶ Tilt the refrigerator to the required angle. Detach the screws fixing the lower hinge and
remove the hinge.
⑷ Fix the lower hinge to the bottom of the other side of the cabinet. Then, mount the lower door
on the lower hinge.
⑸ Take out the 3 hole plugs on the other side of the cabinet.
Turn the middle hinge by 180 degrees and install it on the other side of the cabinet. Attach the
3 screws removed in step 1. Mount the 3 hole plugs into the holes where the hinge is seated
originally.
Note: For 3-door refrigerators, the operation concerning the lower hinge is not needed.
4.5 Removing the Freezer Drawer
(1) Open the freezer storage compartment door of the 3-door refrigerator;
(2) Take out the drawer;
(3) Detach the screw connecting the rail and the support iron (the screw may be on the inner
side of the support iron due to the rail);
(4) Remove the door.
１４
