Normal Wash
Selected wash Option(s) Type Procedure
Heated dry Press SELECT button 1 time
Upper Wash Press SELECT button 2 times
Heated Dry & Upper Wash Press SELECT button 3 times
Note: Hi-Temp Wash option is not available under Normal Wash.
Light Wash
Selected Wash Option(s) Type Procedure
Heated Dry Press SELECT button 1 time
Upper Wash Press SELECT button 2 times
Heated Dry & Upper Wash Press SELECT button 3 times
Note: Hi-Temp Wash option is not available under Light Wash.
Rinse & Hold
Selected Wash Option(s) Type Procedure
Upper Wash Press SELECT button 1 Time
Note: Hi-Temp Wash &Heated Dry options are not available under Rinse & Hold.
Check List for Wash Process:
1) Make sure all items are loaded in the racks and silverware basket properly.
Note: Do not load tall dishware or cookware items near the middle spray arm
because it may block the spray arm from rotating.
2) Pour the proper detergent into the detergent dispenser.
Note: If rinse aid compartment is empty, add “Rinse Aid” agent at this time.
3) Close the door and latch properly.
4) Turn on the power button.
5) Select your desired wash program and option(s) based on the load and soil type.
6) Press the “START/PAUSE” button once to start the wash process. Press this button
once again if you want to “Pause” the activity during the wash process in order
to add or remove items.
Note: Selected wash program and option(s) blinking light(s) will indicate that the
wash process has begun and is running. When paused, the selected wash
program and option(s) light(s) will be still. This indicates that wash
process is paused.
11
