Haier H2SM-(9+12)HEK03/R2 User Manual

H2SM-(9+12)HEK03/R2
6SHFL¿FDWLRQV
Domestic Air Conditioner
8
Outdoor Unit
Casing Color Ivory White
Compressor
Type Rotary compressor
Model 44A203A(9K)/PA118X1C-4FZ(12K)
Motor Output W 850(9K)/970(12K)
Oil Type
NMOCZE-Gles RB68EP(9K)/
ESTER OIL VG74(12K)
Oil Charge L 270/350
Refrigerant
Model R410A
Charge kg 0.85(9K)+1.15(12K)
Air Flow Rate
(cooling/
kHeating)
m
3
/min(High) 31.3/27.7
m
3
/min(Low) 20.5/16.8
cfm(High) 1104/977
cfm(Low) 723/593
Fan
Type Propeller fan
Motor Output W35
Running Current
9K/12K/(9+12)K
Norminal
Cooling
A 3.9/4.5/8.4
Heating A 3.8/4.3/8.1
Maximum
Cooling
A 5.3/5.8/11.1
Heating A5.4/5.9/11.3
Starting current
Cooling
A 21.5/15/-
Heating A 21.5/15/-
Dimensions (H×W×D)(stop valve, and
bottom support is not included)
mm 820×682×310
Packaged Dimensions (H×W×D) mm 949×745×406
Weight
kg 56
Gross Weight
kg 60
Operation Sound H/L
dBA
54
Sound Power
H/L dBA
Note: The data are based the conditions shown in the table below.
Cooling Heating Piping Length
Indoor: 27°CDB/19°CDB
Outdoor: 27°CDB/19°CDB
Indoor: 20°CDB
Outdoor: 7°CDB/6°CDB
5m
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m
3
/min×35.3

Haier H2SM-(9+12)HEK03/R2 Specifications

General

Brand	Haier
Model	H2SM-(9+12)HEK03/R2
Category	Air Conditioner
Language	English
