Haier H2SM-(9+12)HEK03/R2 User Manual

H2SM-(9+12)HEK03/R2
6SHFL¿FDWLRQV
Domestic Air Conditioner
7
6SHFL¿FDWLRQV
Model
H2SM-(9+12)HEK03/R2
Cooling Heating
Capacity Rated(Min.~Max.)
kW 2.7/3.1/5.8 2.9/3.3/6.2
Btu/h 9215/10580/19795 9897/11262/21160
kcal/h 2322/2666/4988 2494/2838/5332
Mositure Removal L/h 1.2/1.5/2.5 —
Running Current(Read) A 3.9/4.5/8.4 3.8/4.3/8.1
Power Consumption
Read(Min.~Max.)
W 885/1015/1900 850/970/1820
Power Factor % 97 97
COP Rated (Min.~Max.) W/W 3.05/3.05/3.05 3.41/3.41/3.41
Piping
Connctions
Liquid mm ĭ
Gas mm ĭ
Drain mm ĭ
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 15
Max. Interunit Height
Difference
m10
Chargeless m 5
Amount of Additional
Charge of Refrigerant
g/m 20
Indoor Unit
Front Panel Color White
Air Flow Rate m
3
/min(cfm)
9K 12K
H 7.5 8.0
M 6.5 7.5
L 5.5 6
Fan
Type Cross Flow Fan
Motor Output W20
Speed Steps 3 Steps and Auto
Air Direction Control
Right / Left / Horizontal / Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated)
A 0.13
Power Consumption (Rated) W29
Power Factor %97
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 265×795×187
Packaged Dimensions (H×W×D) mm 360×871×304
Weight
kg 8.8
Gross Weight
kg 11.3
Operation Sound H/M/L
dBA 39/34/29 38/33/31
Sound Power
H dBA 54 54

Haier H2SM-(9+12)HEK03/R2 Specifications

General

Brand	Haier
Model	H2SM-(9+12)HEK03/R2
Category	Air Conditioner
Language	English
