10- Installation
10.6 Fine tuning of the doors
If the doors are not in one level, this mismatch can be
remedied by following:
10.6.1 Using adjustable foot
Rotate the adjustable foot according to the direction of
arrow i(Fig. 10.6-1) to turn up or down the foot.
10.6.2 Using spacers
▶ Open the upper door and lift it.
▶ Carefully clip the spacer (enclosed in the accessory
bag) in the white plastic ring of the middle hinge by
hand or using tools like pliers (Fig. 10.6-2). Do not
scratch or bruise the door.
10.6-1
29
10.5 Aligning the appliance
The appliance should be placed on a at and solid sur-
face.
1. Tilt the appliance slightly backwards (Fig. 10.5).
2. Set the feet to the desired level.
3. The stability can be checked by alternately bump-
ing on the diagonals. The slightly swaying should
be the same in both directions. Otherwise the
frame can warp; possible leaking door seals are
the result. A low tendency to the rear facilitates
the closing of the door.
max 45°
1.
2.
3.
10.5
Notice: Levelling
In the future use of refrigerator, doors uneven phenomenon may occur to the weight of
stored food. Then please adjust according to the above methods.
10.6-2
