Haier HB18FGSAAA - Product Description; Product Components Overview

GB
3- Product description
Notice: Dierences
Due to technical changes and dierent models, some of the illustrations in this manual
may dier from your model.
A: Refrigerator compartment
1 Rating plate
2 Refrigerator LED lamp
3 ABT sterilisation module
4 Glass shelf
5 O.K.-temperature indicator (optional)
6 Door rack
7 Panel of DryZone drawer
8 Door beam
9 Air duct
10 Door rack
11 Turning cover of Fruit and vegetable drawer
12 Fruit and vegetable drawer
16 Freezer box
17 Upper freezer storage drawer
18 Pre-Freezing tray
19 Fresher Pad
20 Lower freezer storage drawer
21 Adjustable feet
22 Ice maker
23 Freezer drawer handle
B: Freezer compartment
B
8
10
11
13
9
12
14
15
23
3
4
7
19
18
20
16
A
21
1 2
5
6
22
17
3
13 Panel of MoistZone drawer
14 MoistZone drawer
15 DryZone drawer
9
Picture of appliance (Fig. 3)
