10- Installation
10.1 Unpacking
▶ Take the appliance out of the packaging.
▶ Remove all packaging materials.
10.2 Environmental conditions
The room temperature should always be between 10° C and 43° C, since it can inuence
the temperature inside the appliance and its energy consumption. Do not install the appli-
ance near other heat-emitting appliances (ovens, refrigerators) without isolation.
10.3 Space requirement
Required space when door is opened (Fig. 10.3):
D1
D2
D3
D4
D5
W1
W2
10.3
WARNING!
▶ The appliance is heavy. Always handle with at least two persons.
▶ Keep all packaging materials out of children´s reach and dispose them in an environ-
mentally friendly manner.
10.4 Ventilaton cross-section
To achieve sucient ventilation of the appliance for
safety reasons, the information of the required venti-
lation cross sections must be observed (Fig. 10.4).
>10 cm
>10 cm
>10 cm
83 cm
190 cm
10.4
10.5 Aligning the appliance
The appliance should be placed on a at and solid sur-
face.
1. Tilt the appliance slightly backwards (Fig. 10.5).
2. Set the feet to the desired level.
3. The stability can be checked by alternately bump-
ing on the diagonals. The slightly swaying should
be the same in both directions. Otherwise the
frame can warp; possible leaking door seals are
the result. A low tendency to the rear facilitates
the closing of the door.
max 45°
1.
2.
3.
10.5
31
Width
in mm
Depth
in mm
Distance to wall
in mm
W1 W2 D1 D2 D5
830 1424
600 885
50D3 D4
1034 1130
