Haier HB21FNN - Ice Bin and Freezer Drawer Removal

- 10 -
Remove the door and place it in a
proper position.
Remove the middle hinge
if necessary.
Replace the door in a reverse sequence of removal.
Removing & Replacing Ice Bin
Pull out the ice bin entirely and remove
it from the refrigerator.
Release the buckles on both sides
and pull out the bin in the direction
shown on the slideway and remove
it from the refrigerator.
Replace the ice bin in a reversal sequence to removal.
Removing & Replacing Freezer Drawer
Pull out the freezer drawer entirely
and remove it from the refrigerator.
Release the buckles on both sides and
pull out the drawer door in the direction
shown on the slideway and remove it
from the refrigerator.
Replace the freezer drawer in a reversal sequence to removal.
