cooling capacity curves
0
1000
2000
3000
4000
5000
6000
43/30.3 35/24 25/16.3 15/8.6
Outdoor DB/WB
cooling capacity(W)
27/16
27/19
27/20
27/21.5
power input curves in cooling mode
0
500
1000
1500
2000
2500
3000
43/30.3 35/24 25/16.3 15/8.6
Outdoor DB/WB
Cooling power input
（
W
）
27/16
27/19
27/20
27/21.5
Heating capacity curves
3000
3500
4000
4500
5000
5500
6000
6500
7000
7500
8000
16/10 18/12 20/14.5 22/16 24/17 26/18
indoor DB/WB
Heating capacity (W)
-7
-5
0
7
10
15
cop curves in heating mode
2.5
3.0
3.5
4.0
4.5
16/10 20/14.5 24/17
indoor DB/WB
COP
-7
-5
0
7
10
15
