Page #224 background imageLoading...
Page #224 background image
N L1 L2 L3 S
CN11
CN3
CN10 CN2 CN1
CN8
LED
CN9
CN7
CN4
0010451429 for HBU-42CH03, HBU-42CI03, HCFU-42CH03, HDU-42CH03/H, HDU-42CI03/H,
HPU-42CV03 and HPU-42CH03 outdoor unit
-224-
Wiring diagram and PCB photo
