Drain Hose
Swing fender
Refrigerant pipe
Cable line
Earthing line
Air filter
Outlet
Suction grill
(located in the suction grill)
In cooling operation, to
discharge the water
from inside the room.
Discharge unit (built in)
(located in the outlet)
Swing louver
(Air flow direction can be adjusted by using
the SWING button on the remote controller)
Air Inlet Grille
Air Filter
(Inside of the Inlet Grille)
Operating Control Panel
4. Part name
For HBU-28/42CF03 and HBU-28/42HF03
For HBU-18CF03, HBU-18HF03
(
adjust air outlet direction
by the air direction adjusting
button on remote controller)
Air ourlet blade
Suction grill
Air filter
located in the suction grill
HBU-28/42CH03, HBU-28HH03, HBU-42CI03, HBU-42HI03
-27-
Part name
