Standard accessories:
The following installation parts are furnished.
Use them as required.
INSTALLATION PROCEDURE
PREPARING INDOOR UNIT INSTALLATION
1. REMOVE THE INTAKE GRILL
Install the room air conditioner as follows:
Open the intake grill and remove the
three or four or six screws.(Fig. 1)
When the directions are selected, drill a 7 cm dia. hole on the wall so
that the hole is tilted downward toward the outdoor for smooth water
flow. When the pipe is led out from the rear, make a hole in Fig.6, at
the position shown.
(Fig.3)
Drain hose (Left side) Drain hose (Right side)
Remark: The main unit can be wired before
the indoor unit is installed. Select
the most appropriate installation
order.
A. FLOOR CONSOLE TYPE
1. DRILLING FOR PIPING
Select piping and drain directions.(Fig.2)
The piping and drain can be made in three directions as shown below.
down
Pipe connection requirement
(Fig. 1)
Machine screw
Tapping screw
Tapping screw
Intake grill
(Fig. 2)
rear
right
1
2
3
4
5
1
2
4
1+1
2+2
No.
Accessory parts
Qty.
Remote controller
Battery
Wire clamp
Heat
insulation
sheathing
Screw
Screw cap
Remote
controller
bracket
6
7
1
1+1
The drain hose can be connected to either the left or right side.(Fig.3) For series 28
only right side.
IaWX^
A\T_XfXd
H\cg\W e\WX
DTe e\WX
ITj\_g_
^X`Zf[
ITj\_g_ [X\Z[f -UXfiXX`
\`Waad T`W agfWaad.
<185 __
481;; __
63 _
53 _
E@CP05;@C36 E@CP05;EC36
9168 __
451: __
48 _
8_
E@CP04;@C36 E@CP04;EC36
5. Installation
5.1 For series 18, 28
Installation
