Control panel
GB
9
10
1
3
5
6
21
23
24
14
18
19
12
8
13
16 22
25
11
7
4
20
15
17
2
Model (HCR7918ENMP)
(Without Icemaker in door)
1 Vertical beam
2 Control panel
3 Glass shelves
4 Bottle holder/Door rack
5 Humidity zone drawer
6 Storage drawer
7 Handle lamp
8 Air duct and sensor (behind panel)
9 Back lamp
10 Bottle holder/Door rack
11 Air duct (behind drawers)
12 My Zone drawer
13 Freezer/Switch Zone lamp
A: Fridge compartment
14 Sliding tray
15 Water box
16 Air duct
17 Icemaker
18 Freezer storage drawers
19 Ice box
20 Bottle holder
21 Sliding tray
22 Air duct
23 Switch Zone drawers
24 Bottle holder
25 Adjustable feet
B: Freezer compartment
C: Switch Zone compartment
