Haier HF50CW10W - Chapter 5 Control and Display System; Control Panel; Starting the Freezer

SERVICE MANUAL
Model: HF50CW10W
11
Issue 2014-1-24
Rev.
Ref1401S002V0
Chapter 5 Control and display system
5-1. Control panel
Freezing temperature selection is made by setting the control from 1to 7(coldest).
If we want colder or warmer temperatures, adjust the control one step at a time.
Allow several hours after each one-step adjustment for the freezer temperature to
stabilize.
5-2. Starting the Freezer
1. Clean the inside of the freezer with a mild solution of baking soda and water
2. Connect cord to power outlet.
3. On models with a Temperature Monitor or High-Temp Alarm Switch, set the switch to the Min
position.
4. Make sure the temperature control is set at 4.
5. Allow freezer to operate for at least four hours before placing food inside.
6. On models with a Temperature Monitor or High-Temp Alarm Switch, set the switch to the ON
position.
