SERVICE MANUAL
Model: HF50CW10W
12
Issue 2014-1-24
Rev.
Ref1401S002V0
Chapter 6 System flow principle
6-1. Refrigeration flow chart
The refrigeration system of direct cooling single-system cooler belongs to the category of a
single-temperature and single-control refrigerating system with one evaporators and is controlled by a
single temperature control.
6-2. Refrigeration flow scenograph
