A
Removable Washer
B
Secondary Washer (Do not
remove)
C
Washer Support (Do not
remove)
D
Silver Faucet Connector
NOTE: The faucet connector (provided) is threaded so that it will t MOST
faucets. If the provided faucet connector does not
t your faucet, you will
need to purchase a faucet connector in the correct size.
3. Thread the silver faucet connector onto the faucet.
Internal Threads
A
Rubber Washer
B
Silver Faucet Connector
C
Quick-sink Faucet Adapter
D
Water Inlet Hose - Gray End Only
4. Attach the quick-sink faucet adapter by hand to the gray end of the inlet hose
until rmly hand tightened making sure the pre-installed at washer is between
the hose and the adapter. Then follow additional tightening instructions for
Style 1 or Style 2.
Style 1 - Using pliers, tighten the connection an additional two-thirds turn
(MAXIMUM). Do not use excessive force.
Style 2 - Do not use pliers to tighten the connection.
IMPORTANT: To avoid damage to the hose couplings, do not overtighten.
NOTE: To avoid damage to the faucet, do not use plumber’s tape or
sealants on the valve threads.
5. Attach the quick-sink faucet adapter to the silver faucet connector by pulling
down on the white collar while pushing upwards on the faucet. Release the
white collar and it will lock into place.
6. Turn on the water faucet and check for leaks. If there is any leaking:
•
Check for loose connections and tighten.
•
Make sure the gray end is connected to the Quick-sink Faucet Adapter and
the white end is connected to the washing machine.
7. Using two cable ties, fasten the water inlet hose to the drain hose so that the
hoses will stay in place.
19
ENGLISH
