Haier HP200M3 Installation And Service Manual

5
3. Technical parameters
Model
HP200M3
HP250M3
HP250M3C
Tank
Tank volume
195L
246L
240L
Rated voltage/ frequency
220V~240V/50Hz
220V~240V/50Hz
220V~240V/50Hz
Tank rated pressure
0.7MPa
0.7MPa
0.7MPa
Corrosion protection
Magnesium rod
Magnesium rod
Magnesium rod
Water proof grade
IPX4
IPX4
IPX4
Performances
Type of extraction
Ambient / Exterior
Ambient / Exterior
Ambient / Exterior
COP@7 ℃ /EN16147
3.04
3.02
3.10
COP@14 ℃ /EN16147
3.39
3.41
3.56
Tapping cycle
L
L
L
Power input by electric backup
1500W
1500W
1500W
Rated power input by heat pump
495W
495W
495W
Maximum power input by heat pump
865W
865W
865W
Maximum power input
2365W
2365W
2365W
Standby power input/ Pes
27W
27W
27W
Max volume of usable hot water at 40 ℃
setting at 55 ℃
224L
311L
332L
Heating up time (7 ℃ )
5.5 h
7.35h
6.92h
Heating up time (14 ℃ )
4.68h
6.17h
6h
Default temperature setting
55℃
55℃
55℃
Temperature setting range- with heater
35℃-75℃
35℃-75℃
35℃-75℃
Maximum length of air inlet duct
2.5m
2.5m
2.5m
Maximum length of air outlet duct
2.5m
2.5m
2.5m
Max working pressure of refrigerant
0.8/2.8MPa
0.8/2.8MPa
0.8/2.8MPa
Refrigerant type / weight
R134a/0.9kg
R134a/0.9kg
R134a/0.9kg
Sound power level
57dB
58dB
59dB
Ambient temperature for use of product
-7~35℃
-7~35℃
-7~35℃
Operating temperature of heat pump
-7~35℃
-7~35℃
-7~35℃
Dimension and connections
Water inlet and outlet connection
G3/4"F
G3/4"F
G3/4"F
Safety valve connection
G3/4"F
G3/4"F
G3/4"F
Drain & Water intlet connection
G3/4"F
G3/4"F
G3/4"F
Product Dimensions
600*629*1692mm
600*629*1987 mm
600*629*1987 mm
Packing dimension without pallet
736*695*1810 mm
736*695*2120 mm
736*695*2120 mm
Packing dimension with pallet
736*695*1940 mm
736*695*2250 mm
736*695*2250 mm
Net/Gross weight
91/103kg
102/115kg
119/132kg
* The COP and noise level data was tested in Haier lab
