Installation introduction
Air connection
- Remove air grille first.
- Install diameter 180mm duct.
- Pressure drops from duct must be lower than or equal to the static pressure of
the fan.
- If the pressure drops out of range, the performance of the appliance will be
impaired.
The sum of the maximum length of the air duct is 5m．
14
