7
Technical parameters
Model HP200M3 HP250M3 HP250M3C
Tank volume 195L 246L 240L
Rated voltage/ frequency 220V~240V/50Hz 220V~240V/50Hz 220V~240V/50Hz
Tank rated pressure 0.7MPa 0.7MPa 0.7MPa
Corrosion protection Magnesium rod Magnesium rod Magnesium rod
Water proof grade IPX4 IPX4 IPX4
Type of extraction Ambient / Exterior Ambient / Exterior Ambient / Exterior
COP@7
℃
/ EN16147 3.04
3.02
3.10
COP@14
℃
/ EN16147 3.39 3.41 3.56
Tapping cycle L L L
Power input by electric backup 1500W 1500W 1500W
Rated power input by heat pump 495W 495W 495W
Maximum power input by heat pump 865W 865W 865W
Maximum power input
2365W
2365W
2365W
Standby power input/ Pes
27W 27W
27W
Max
volume of usable hot water at 40
℃
setting at 55
℃
223L 305L 303L
Heating up time (7
℃
)
5.50h 7.35h 6.92h
Heating up time (14
℃
) 4.68h 6.17h
6.00h
Default temperature setting
55
℃
55
℃
55
℃
Temperature setting range- with heater 35
℃
-75
℃
35
℃
-75
℃
35
℃
-75
℃
Maximum length of air duct
180mm
Max working pressure of refrigerant 0.8/2.8MPa 0.8/2.8MPa 0.8/2.8MPa
Refrigerant type / weight R134a/0.9kg R134a/0.9kg R134a/0.9kg
Sound power level 60dB 60dB 60dB
Ambient temperature for use of product -7~35
℃
-7~35
℃
-7~35
℃
Operating temperature of heat pump -7~35
℃
-7~35
℃
-7~35
℃
Water inlet and outlet connection G3/4"F G3/4"F G3/4"F
Safety valve connection G3/4"F G3/4"F G3/4"F
Drain & Water intlet connection G3/4"F G3/4"F G3/4"F
Product Dimensions
600*629*1692mm 600*629*1987 mm 600*629*1987 mm
Packing dimension without pallet
736*695*1810 mm 736*695*2120 mm 736*695*2120 mm
Packing dimension with pallet
736*695*1940 mm 736*695*2250 mm 736*695*2250 mm
Net/Gross weight 91/103kg 102/115kg 119/132kg
* The COP and noise level data was tested in Haier lab
Tank
Performances
Dimension and connections
English
Diameter of air duct connection
5m 5m 5m
180mm 180mm
