7
Technical parameters
Model HP80M5 HP110M5
Tank volume 82L 105L
Rated voltage/ frequency 220V~240V/50Hz 220V~240V/50Hz
Tank rated pressure 0.8MPa 0.8MPa
Corrosion protection Magnesium rod Magnesium rod
Water proof grade IPX4 IPX4
Type of ex
●
traction Ambient / Exterior Ambient / Exterior
COP@7 / EN16147 2.74
2.73
COP@14 / EN16
●
147 3.04 3.02
Tapping cycle M M
Power input by electric backup 1200W 1200W
Rated power input by heat pump 240W 240W
Maximum power input by heat pump 350W 350W
Maximum
●
power input
1550W
1550W
Standby power input/ Pes
21W 21W
Max volume of usa
●
ble hot water at 40
setting at 55
103L 132L
Heating up time (7 )
5h07 6h38
Heating up time (14 ) 4h35 5h56
Default temperature setting
54
54
Temperature setting range- with heater 35 -75 35 -75
Maximum length of air duct
160mm
Max working pressure of refrigerant 0.8/2.8MPa 0.8/2.8MPa
Refrigerant type / weight R134a/0.45kg R134a/0.45kg
Sound power level 50dB
(A)
50dB
(A)
Ambient temperature for use of product -7~45 -7~45
Operating temperature of heat pump -7~45 -7~45
Water inlet and outlet connection G1/2"M G1/2"M
Safety valve connection G1/2"M G1/2"M
Drain & Water intl
●
et connection G1/2"M G1/2"M
Product Dimensions
492*537*1170mm 492*537*1320 mm
Packing dimension without pallet
587*587*1247mm 587*587*1397 mm
Net/Gross weight 52/59kg 65/73kg
* The COP and noise level data was tested in Haier lab.
Tank
Performances
Dimension and connections
English
Diameter of air duct connection
5m 5m
160mm
