Assembly and Installation
1. Attach one end of the exhaust hose to the exhaust duct adapter.
2. The exhaust duct adapter slides into the rear of the air conditioner
over the exhaust duct.
3. The other end of the exhaust hose attaches to the hose nozzle.
4. The hose nozzle attaches to the window panel kit which rest on
the window.
Exhaust Duct Adapter
Exhaust Duct Hose
Hose Nozzle
Adaptateur du Conduit de Sortie d’air chaud
Tuyau du Conduit de Sortie d’air chaud
Embout de Tuyau
Exhaust duct
Hose Nozzle
Window Panel Kit
(6)
