Haier HRF328S2 - Control and Display System; Control and Display Panel Overview

SERVICE MANUAL
Model: HRF328
\
368
13
Issue 2015-7-18
Rev.
Ref 1507S002V1
5. Control and display system
5-1. Control and display panel
5-2.
Start-up
■Start-up
1. Insert the plug in the socket to switch on the refrigerator.
2. Display will show you the actual temperature.When Display show “H” ,it means that the ambient
temperature is too high; When Display show “L” ,it means that the ambient temperature is too low.
