Haier HRF328S2 - Issue 2015

SERVICE MANUAL
Model: HRF328
\
368
7
Issue 2015-7-18
Rev.
Ref 1507S002V1
Handle
(External/Metal/Integrated)
External(assisst
ant)
External(assisst
ant)
Available colours
White White
7.
Interior description
Fridge compartment:
Shelves:
Number (Total / adjustable) n° / n°
4/4 4/4
Type (gr=grill / g=glass /
p=plastic)
g g
Colour (w=white / lb=light blue /
g=green / t=transpar.)
t t
Bottle holder / bottle(s) n° / n°
1/5 1/5
Chiller compartment / drawer
0 1
Crisper(s):
Number / colour t = transparent, w
= white
n° / -
1/t 1/t
Shelf (on salad crisper)
(g=glass / p=plastic)
p p
Door:
Storage rack(s)
(Total)
n° / n° 4 4
Butter and cheese compartment 0 0
Type of rack(s) g=glass /
p=plastic
p p
Inside colour
White White
Reversible door
● ●
Lock
- -
Self closure mechanism
- -
Freezer compartment:
Drawer(s) n°
/ /
Basket(s) n°
/ /
Flap(s) n°
/ /
Ice tray n°
/ /
Adjustable temperature drawer n°
/ /
Colour of drawer (w=white, t=transp.,
g=green, gr=gray)
/ /
Shelf number /
p=plastic, g=glass ,W=wire
n° / n°
/ /
Door rack(s) number / p=plastic,
g=glass
/ /
