13. Change the positions of the blanking plugs and the
screw on the side.
a.Remove lower door.
b. Change the positions of the blanking plug at the top of
the lower door.
c.Change the door stop at the bottom of the lower door
from the current position to opposite side.
d.Unscrew the lower hinge.
e.Take out the new lower hinges from the accessory bag
and screw the new lower hinge to the other side of the
door opening.
f.Lift the lower door carefully on to the lower hinge so
that the pivot fits into the hinge barrel.
14.Take out the new hinges from the accessory bag and
screw the new lower hinge of upper door to the other
side of the door opening.
15.Lift the door carefully on to the lower hinge so that
the pivot fits into the hinge barrel.
16.Fix the upper hinge with the screws.
17.Put the connection cable through the hinge
cover(delivered in the accessory bag)and put it over the
hinge.
18.Plug in the connection cable and fit it into the
opening.
19. Replace faceplate and cover, fix it with the screws and
reinsert the fixation (see fig .3).
After the change of the door check that the door seals are
located properly on the housing and all screws are
tightened well.
