① As shown in the figure, unscrew
three bolts from the refrigerator air duct
with a cross screwdriver;
② Follow the arrow direction in the
figure and remove the refrigerator air
duct from top to bottom;
③ Pull out the terminal that is
connected to variable temperature
sensor from the right side of
refrigerator air duct. Then, the
refrigerator air ducts in the left and
right can be removed.
The small terminal is a cold storage
sensor, and the big terminal is a
variable temperature sensor.
