Equipment
25
D1
D2
D3
Stop
Limit
Ice cube tray
1. Fill the ice cube tray 3/4 full of water, close with the
cover and put it into the pre-freezing compart-
ment.
2.
-
ing water to loosen the ice cubes.
Removable freezer drawer
The freezer drawers are removable:
1.Pull out the drawer to the maximum extent.
2. Lift the drawer and remove.
Drawer D2
1. Pull out the drawer to maximum extent,
2. Press the Stop limit on both sides.
3. Lift the drawer and remove.
1. Pull out the drawer to maximum extent.
2. Lift to separate the box from the rails and remove.
In order to insert the boxes and drawer, the above
steps are carried out in reverse order.
Insert water tank
(only models with water dispenser)
Place the water tank in the position that the water out
-
the water tank is locked.
A
B
Removable water tank
(only models with water dispenser)
The water tank can be removed and reinstalled f
or
cleaning in the same way as the door racks.
D1
D2
D4
