Installation
13. Change the positions of the blanking plugs and
the screw on the other side.
After changing the door check that the door seals
are located properly on the housing and all screws are
tightened well.
a Remove lower door.
b Change the door stop at the bottom of the lower
door from the current position to opposite side.
c Unscrew the bottom hinge.
d Take out the new bottom hinge from the acces-
sory bag and screw the new bottom hinge to the
other side of the door opening.
e Lift the lower door carefully onto the bottom hinge
so that the pivot ts into the hinge barrel.
a
b
c
d e
14. Take out the new hinge from the accessory bag
and screw the new middle hinge of upper door to
the other side of the door opening.
14.
13.
Be sure the pivot ts into the hinge barrel of lower
door.
15. Lift the door carefully on to the lower hinge so
that the pivot ts into the hinge barrel.
16. Fix the upper hinge with the screws.
17. Put the connection cable through the hinge
cover (delivered in the accessory bag) and put it
over the hinge.
18. Plug in the connection cable and t it into the
opening.
19. Replace faceplate and cover, x it with the screws
and reinsert the xation (see g. 3).
15. 16.
17. 18.
19.
