Parts and Functions
Indoor unit
13
OUTLET CONNECTING PIPING AND ELECTRICAL WIRING
INLET DRAIN HOSE
Display board
The conversion of pilot light's colors will be displayed as
the figure under different operation models
OPERATE
RED
RED
GREEN
GREEN
GREEN
YELLOW
COOL DRY HEAT TIMER HEALTH
Display board
Inlet
Anion generator
Vertical flap
(Use remote controller to
adjust up and down air flow.
Don't adjust it manually)
Horizontal louver
Air filter
Inlet grille
(inside)
(adjust left and right air flow)
(inside)
For multi-split type, the power plug is on the outdoor unit
3
4
1
2
Outdoor unit
