+6807C03  &RQQHFWRU:LULQJ'LDJUDP
3ULQWHG&LUFXLW%RDUG&RQQHFWRU:LULQJ'LDJUDP
,QGRRU8QLW 
'RPHVWLF$LUFRQGLWLRQ
9
1.1 Indoor unit
Connectors PCB
1) CN1 connector for transformer˄primary coil˅
2) CN2 connector for terminal block
3) CN3 connector for ransformer˄secondary coil˅
4) CN5 connector for louver motor
5) CN6 connector for ambient temp. sensor and piping temp.sensor
6) CN7 connector for receiver dislay
7) CN8 connector for indoor AC fan motor
8) CN9 connector for indoor AC fan motor
