NO Parts code Name of part Part QTY. Easily damaged
components (Y/N)
1 001A0100945 Inlet grille 1
2 001A2400058 Air filter 2
3 001A0100944 Front panel 1
4 001A1232077 Flap 1
5 001A0900048 Drain pan 1
6 0010705494 Evaporator 1
7 001A0300005 bearing 1
8 0010202415 Cross flow fan 1
9 001A0100199 Frame assy. 1
10 0010101275 Mounting plate 1
11 001A3000051 Fan motor 1
Y
12 0010400100 Transformer 1
Y
13 0010402953 PCB 1
Y
14 001A4000091 Terminal block 1
15 0010402241 Receiver board 1
Y
16 001A0900011 Drain hose 1
17 001A3000072 Swing motor 1
18 0010402639 Remote controller 1
Y
19 001A1434039 Drain tube 1
20 001A3900059 Sensor 1
Y
Parts list :HSU-09C03/Z1 Indoor unit
Domestic Air Conditioner Model: HSU-09C03/Z1
HSU-12C03/Z1
Domestic Air ConditionerDomestic Air Conditioner
