Haier HSU-12C03/Z1 User Manual

NO Parts code Name of part
Part
QTY. Easily damaged
components (Y/N)
1 001A0100945 Inlet grille assy. 1
2 001A2400060/001A
2400061
Air filter 1
3 001A0100944 Front panel assy. 1
4 001A1232077 Flap 1
5
001A0900048
Drain pan assy. 1
6
0010702158
Evaporator assy. 1
7 001A0300005 Bearing 1
8 0010202415 Cross flow fan 1
9 001A0100206 Frame assy. 1
10 0010101275 Mounting plate 1
11 001A3000052 Fan motor 1
y
12
0010402315
Transformer 1
y
13
0010402955
PCB 1
y
14 001A4000091 Terminal block 1
15 0010402241 Receiver board 1
y
16 001A0900011 Drain hose 1
17 001A3000072 Swing motor 1
y
18 0010402639 Remote controller 1
y
19 001A1434039 Drain tube 1
20 001A3900059 Sensor
Parts list :HSU-12C03/Z1 indoor unit
Domestic Air Conditioner Model: HSU-09C03/Z1
HSU-12C03/Z1
Domestic Air ConditionerDomestic Air Conditioner
20
