Haier HSU12VHG-B - Outdoor Unit

HSU12HG(DB)-SM Wiring Diagrams
31
Domestic Air Conditioner
92 1.0910 0.9882 0.8942 -3.69 3.37
93 1.0607 0.9599 0.8679 -3.74 3.42
94 1.0314 0.9326 0.8424 -3.80 3.46
95 1.0030 0.9061 0.8179 -3.85 3.51
96 0.9756 0.8806 0.7941 -3.90 3.55
97 0.9490 0.8558 0.7711 -3.96 3.60
98 0.9232 0.8319 0.7489 -4.01 3.64
99 0.8983 0.8088 0.7275 -4.07 3.69
100 0.8741 0.7863 0.7067 -4.12 3.74
101 0.8507 0.7646 0.6867 -4.18 3.78
102 0.8281 0.7436 0.6672 -4.23 3.83
103 0.8061 0.7233 0.6484 -4.29 3.88
104 0.7848 0.7036 0.6303 -4.34 3.92
105 0.7641 0.6845 0.6127 -4.40 3.97
106 0.7441 0.6661 0.5957 -4.46 4.02
107 0.7247 0.6482 0.5792 -4.51 4.07
108 0.7059 0.6308 0.5632 -4.57 4.12
109 0.6877 0.6140 0.5478 -4.63 4.16
110 0.6700 0.5977 0.5328 -4.69 4.21
111 0.6528 0.5820 0.5183 -4.74 4.26
112 0.6361 0.5667 0.5043 -4.80 4.31
113 0.6200 0.5518 0.4907 -4.86 4.36
114 0.6043 0.5374 0.4775 -4.92 4.41
115 0.5891 0.5235 0.4648 -4.98 4.45
116 0.5743 0.5100 0.4524 -5.04 4.50
117 0.5600 0.4968 0.4404 -5.10 4.55
118 0.5460 0.4841 0.4288 -5.16 4.60
119 0.5325 0.4717 0.4175 -5.22 4.65
120 0.5194 0.4597 0.4066 -5.28 4.70
5.3.2 Outdoor Unit
Ambient Sensor, Defrosting Sensor, Pipe sensor
R25ć=10K¡f3% B25ć/50ć=3700Kf3%
Temp.(ć)
Max.(KΩ) Normal(KΩ) Min.(KΩ)
Tolerance(ć)
-30 165.2170 147.9497 132.3678 -1.94 1.75
-29 155.5754 139.5600 125.0806 -1.93 1.74
-28 146.5609 131.7022 118.2434 -1.91 1.73
-27 138.1285 124.3392 111.8256 -1.89 1.71
-26 130.2371 117.4366 105.7989 -1.87 1.70
-25 122.8484 110.9627 100.1367 -1.85 1.69
-24 115.9272 104.8882 94.8149 -1.83 1.67
-23 109.4410 99.1858 89.8106 -1.81 1.66
-22 103.3598 93.8305 85.1031 -1.80 1.64
