5.3.2 Outdoor Unit
Ambient Sensor, Defrosting Sensor, Pipe sensor
Functions and Control
313 1.0030 0.9061 0.8179 -3.32 20.232
316 0.9756 0.8806 0.7941 -3.48 20.36
319 0.9490 0.8558 0.7711 -3.672 20.52
323 0.9232 0.8319 0.7489 -3.832 20.648
326 0.8983 0.8088 0.7275 -4.024 20.808
329 0.8741 0.7863 0.7067 -4.184 20.968
332 0.8507 0.7646 0.6867 -4.376 21.096
335 0.8281 0.7436 0.6672 -4.536 21.256
339 0.8061 0.7233 0.6484 -4.728 21.416
342 0.7848 0.7036 0.6303 -4.888 21.544
345 0.7641 0.6845 0.6127 -5.08 21.704
348 0.7441 0.6661 0.5957 -5.272 21.864
351 0.7247 0.6482 0.5792 -5.432 22.024
355 0.7059 0.6308 0.5632 -5.624 22.184
358 0.6877 0.6140 0.5478 -5.816 22.312
361 0.6700 0.5977 0.5328 -6.008 22.472
364 0.6528 0.5820 0.5183 -6.168 22.632
367 0.6361 0.5667 0.5043 -6.36 22.792
371 0.6200 0.5518 0.4907 -6.552 22.952
374 0.6043 0.5374 0.4775 -6.744 23.112
377 0.5891 0.5235 0.4648 -6.936 23.24
380 0.5743 0.5100 0.4524 -7.128 23.4
383 0.5600 0.4968 0.4404 -7.32 23.56
387 0.5460 0.4841 0.4288 -7.512 23.72
390 0.5325 0.4717 0.4175 -7.704 23.88
393 0.5194 0.4597 0.4066 -7.896 24.04
R89=10K¡f3% B89/169 =3700Kf3%
Temp.(

)
Max.(KΩ) Normal(KΩ) Min.(KΩ)
Tolerance()
-87 165.2170 147.9497 132.3678 2.792 14.6
-84 155.5754 139.5600 125.0806 2.824 14.568
-81 146.5609 131.7022 118.2434 2.888 14.536
-77 138.1285 124.3392 111.8256 2.952 14.472
-74 130.2371 117.4366 105.7989 3.016 14.44
-71 122.8484 110.9627 100.1367 3.08 14.408
-68 115.9272 104.8882 94.8149 3.144 14.344
-65 109.4410 99.1858 89.8106 3.208 14.312
-61 103.3598 93.8305 85.1031 3.24 14.248
-58 97.6556 88.7989 80.6728 3.304 14.216
-55 92.3028 84.0695 76.5017 3.368 14.184
-52 87.2775 79.6222 72.5729 3.432 14.12
