Haier HTF-508DGS7 User Manual

Installation
EN
3. The stability can be checked by alternately bum-
ping on the diagonals. The slightly swaying should
be the same in both directions. Otherwise the
frame can warp; possible leaking door seals are
the result. A low tendency to the rear facilitates
the closing of the door.frame can warp; possible
leaking door seals are the result. A low tendency to
the rear facilitates the closing of the door.
Notice
In the future use of refrigerator, doors uneven phenomenon may occur to the weight of
stored food. Then please adjust according to the above methods.
A
32
B) Using spacers
▶ Open the upper door and lift it.
▶ Carefully clip the spacer (enclosed in the accessory
bag) in the white plastic ring of the middle hinge
by hand or using tools like pliers. Do not scratch or
bruise the door.
Fine tuning of the doors
If the doors are not in one level, this mismatch can be
remedied by following:
A) Using adjustable foot
Rotate the adjustable foot according to the direction of
arrow to turn up or down the foot.
3.
B

Haier HTF-508DGS7 Specifications

General

Child lock	No
Display type	LED
Product color	Gray
Product design	French door
Built-in display	Yes
Door gasket type	Snap-in gasket
Shelves material	Glass
Shelf finish type	Silver frame
Custom panel-ready	-
Appliance placement	Freestanding
Number of compressors	1
Fridge net capacity	360 L
Fridge door balconies	6
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	11 kg/24h
Freezer net capacity	177 L
Freezer number of shelves/baskets	4
Storage time during power failure	12 h
Noise level	38 dB
Certification	CE
Climate class	ST
Total net capacity	537 L
Current	1.8 A
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	380 kWh
Package depth	749 mm
Package width	910 mm
Package weight	142000 g
Control position	External

Weight and Dimensions

Depth	669 mm
Width	830 mm
Height	1900 mm
Weight	134000 g
Depth without handle	680 mm
