Haier HTW7720ENMP User Manual

10- Installation
33
GB
10.5 Aligning the appliance
The appliance should be placed on a flat and solid
surface.
1. Tilt the appliance slightly backwards (Fig. 10.5).
2. Set the feet to the desired level.
3.
The stability can be checked by alternately
bumping on the diagonals. The slightly swaying
should be the same in both directions. Otherwise
the frame can warp; possible leaking door seals are
the result. A low tendency to the rear facilitates
the closing of the door.
10.6 Fine tuning of the doors
If the doors are not in one level, this mismatch can be
remedied by following.
10.6.1 Using adjustable foot
Rotate the
adjustable foot according to the direction
of arrow i(Fig. 10.6 -1) to turn up or down the foot.
10.6.2 Using spacers
 Open the upper door and lift it.

Carefully clip the spacer (enclosed in the
accessory bag) in the white plastic ring of the
middle hinge by hand
or using tools like pliers (Fig.
10.6-2). Do not scratch or bruise the door.
Notice: Levelling
In the future use of refrigerator, doors uneven phenomenon may occur to the weight of
stored food. Then please adjust according to the above methods.

Haier HTW7720ENMP Specifications

General

Appliance placement	Freestanding
Refrigerant	R600a
Climate class	SN-T
Noise level	39 dB
Fridge interior light	Yes
Lamp type	LED
No Frost (fridge)	Yes
Multi-Airflow system (fridge)	Yes
Number of vegetable drawers	2
Egg balcony	Yes
Bottle rack	Yes
No Frost (freezer)	Yes
Ice cube tray	Yes
Fresh zone compartment	Yes
Energy Star Certified	No
Fridge number of shelves/baskets	3
Freezer number of shelves/baskets	2
